Image Sensor
|
2MP CMOS Image Sensor
|
|
Signal System
|
PAL/ NTSC
|
|
Effective Pixels
|
1930(H) x 1088(V)
|
|
Min. illumination
|
0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR; 0.014 Lux @ (F1.4, AGC ON), 0 Lux with IR
|
|
Shutter Time
|
1/25(1/30)s to 1/50,000s
|
|
Lens
|
Motorized VF lens; 2.8 - 12 mm @ F1.4
Angle of view: 114.5°- 35.1°
|
|
Lens Mount
|
φ14
|
|
Day & Night
|
ICR
|
|
Angle Adjustment
|
Pan: 0°- 360°; Tilt:0°- 90°; Rotate: 0°- 360°
|
|
Synchronization
|
Internal synchronization
|
|
Video Frame Rate
|
1080p@25fps/1080p@30fps
|
|
HD Video Output
|
1 Analog HD output
|
|
S/N Ratio
|
＞62dB
|
|
Camera ID
|
On/off (0-255)
|
|
AGC
|
Support
|
|
D/N Mode
|
Color/BW/Auto/EXT
|
|
White Balance
|
Auto/User/Push/8000K/6000K/4200K/3000K
|
|
Privacy Mask
|
On/Off, maximum 2 zones
|
|
Motion Detection
|
On/Off, maximum 4 zones
|
|
BLC
|
Support
|
|
Anti-flicker
|
On/Off
|
|
Language
|
English/Chinese
|
|
Functions
|
Digital noise reduction, Mirror
|
|
Power Supply
|
12 VDC±15%
|
|
Power Consumption
|
Max. 5W
|
|
Protection Level
|
IP66
|
|
IR Range
|
Up to 40m
|
|
Communication
|
Up the coax, Protocol: HIKVISION-C(TVI output)
|
|
Dimensions
|
92 x 84.8 x 269.6mm
|
|
Weight
|
900g
|
