Chipset
|
Intel H310
|
|
CPU SUPPORT
|
Socket 1151 for 9th / 8th Gen Intel® Core, Pentium and Celeron processors
Maximum CPU TDP (Thermal Design Power): 95Watt
* Please refer to www.biostar.com.tw for CPU support list.
|
|
MEMORY
|
Supports Dual Channel DDR4 1866/ 2133/ 2400/ 2666
2x DDR4 DIMM Memory Slot, Max. Supports up to 32 GB Memory
Each DIMM supports non-ECC 4/8/16GB DDR4 module
* Please refer to www.biostar.com.tw for Memory support list.
|
|
INTEGRATED VIDEO
|
By CPU model
Supports DX12
Supports HDCP
|
|
STORAGE
|
4 x SATA3 Connector
|
|
LAN
|
RTL8111H
10/ 100/ 1000 Mb/s auto negotiation, Half / Full duplex capability
|
|
CODEC
|
ALC887
7.1 Channels, High Definition Audio
Support HD Audio
|
|
USB
|
4x USB 3.1(Gen1) port (2 on rear I/Os and 2 via internal header)
6x USB 2.0 port (4 on rear I/Os and 2 via internal header)
|
|
EXPANSION SLOT
|
2x PCIe 2.0 x1 Slot
1x PCIe 3.0 x16 Slot
|
|
REAR I/O
|
1x PS/2 Mouse Port
1x PS/2 Keyboard Port
1x HDMI Port
1x VGA Port
1x LAN Port
4x USB 2.0 Port
2x USB 3.1(Gen1) Port
3x Audio Jack
|
|
INTERNAL I/O
|
4x SATA III Connector
1x USB 2.0 Header (each header supports 2 USB 2.0 ports)
1x USB 3.1(Gen1) Header (each header supports 2 USB 3.1(Gen1) ports)
1x 8-Pin Power Connector
1x 24-Pin Power Connector
1x CPU Fan Connector
1x System Fan Connector
1x Front Panel Header
1x Front Audio Header
1x Clear CMOS Header
1x COM Port Header
|
|
DIMENSION
|
Micro ATX Form Factor Dimension: 226mm x 171mm ( W x L )
|
|
OS SUPPORT
|
Support Windows 7/ 10(64bit)
※Biostar reserves the right to add or remove support for any OS with or without notice.
|
|
ACCESSORIES
|
2 x SATA Cable
1 x I/O Shield
1 x DVD Driver
1 x Quick Guide
|
