Hãng sản xuất: ASUS
Chủng loại : H110M-CS
CPU hỗ trợ : Intel® for 6th Generation Socket 1151 Core™ i7/Core™ i3/Pentium®/Core™ i5/Celeron® Processors
Chipset : Intel® H110
Bộ nhớ trong: 2 x DIMM, Max. 32GB, DDR4 2133 MHz Un-buffered, Non-ECC Memory *1
VGA onboard: Integrated Graphics Processor- Intel® HD Graphics support . Maximum shared memory of 1024 MB
Card mạng: Realtek® RTL8111H
Âm thanh
Audio Feature :
- Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
- Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
- Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
Realtek® ALC887-VD2 8-Channel High Definition Audio CODEC *3
- Supports : Jack-detection, Front Panel Jack-retasking
Khe mở rộng
2 x PCIe 2.0 x1
1 x PCIe 3.0/2.0 x16 (x16 mode)
Chuẩn lưu trữ
Intel® Rapid Storage Technology supports*2
Intel® H110 Chipset : gray, 4 x SATA 6Gb/s port(s),
Cổng giao tiếp trước và sau
1 x 14-1 pin TPM connector
4 x SATA 6Gb/s connector(s)
1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
1 x 24-pin EATX Power connector(s)
1 x LPT header
1 x COM port(s) connector(s)
1 x Chassis Fan connector(s) (1 x 4 -pin)
1 x System panel(s)
1 x Chassis intrusion header
1 x Internal speaker connector(s)
1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) (19-pin)
1 x CPU Fan connector(s) (1 x 4 -pin)
1 x Front panel audio connector(s) (AAFP)
1 x 4-pin ATX 12V Power connector(s)
Kích thước: uATX Form Factor 8.3 cm x 7.1 cm ( 21.08 cm x 18.03 cm )
Phụ kiện đi kèm
Drivers
ASUS Utilities
ASUS EZ Update
Anti-virus software (OEM version)
